supply 29 1/2-500PSI hydril MSP Diverter To SLB

29 1/2" 500psi and 30 1000psi Diverter

Manufacturing Standards: API 16A,GB/T 20174
Product Applicability:
It is mainly used for shallow gas control in surface borehole.
The diverter system is a control device that guides the fluid from the well to a place have safe distance, and its purpose is to reduce the wellhead back pressure.
It is also called the diversion system.
Product Features
* The design and manufacture of the diverter comply with API 16A, and the flange specifications meet the requirements of Large
Diameter Steel Flanges (ASME B16.47)
* The upper and lower connection specifications for 29 1/2"-500psi Diverter is class 300 B16/A NPS30 R95
* The upper and lower connection specifications for 30"-1000ps Diverter is class 600 B16/A NPS30 R95
* Appropriate surface treatment methods are adopted for key sealing parts, which can meet the requirements for using in highly
corrosive environment
* Diverter should closed within 45s (Note: Need applicable closing unit to control)

Bore Size 30″
Rated Working Pressure 1000psi Sulfur resistance level NACE MR0175
Performance Level Application example: Southwest of China, Kuwait, Iraq, Kazakhstan, South America
Technical parameter
Bore Size 749.3mm (29 1/2″),762mm (30″)
Rated Working Pressure 3.45MPa (500psi),6.9MPa (1000psi)
Metal material temperature level T-20/250'''
Temperature Ratings for Nonmetallic Sealing Materials Highest BGD
Sulfur resistance level NACE MR0175

Temperature Level Highest 250ºF(121ºC

For the two diverter,client choose the pressure lower 500PSI diverter 29 1/2-500psi.

we produce it and delivery the diverter take 70days,they install it in their well good coonection.

Also I send them two set packing element PN:1003275-02 and repair kit 3106283
